- Power Input (KW): 0.4 ~ 1.36
- Running Current (A): 2.2 ~ 6.5
- Refrigerant: R32
- Air circulation (m³/h): 750
Performance Specifications
-
Capacity wise: 1-Ton
-
Category wise: DC Inverter
-
Color: Golden
-
Cooling Capacity BTU: 13000
-
Running Current Cooling (A): 2.2 ~ 6.5
-
Power input Cooling (KW): 0.4 ~ 1.36
-
Heating Capacity BTU: 13500
-
Running Current Heating (A): 2.3 ~ 6.0
-
Power Input Heating (KW): 0.41 ~ 1.35
Other Parameters
-
Input Power Supply (Ph, VAC, Hz): 1PH,220V Ì´, 50Hz
-
Air Flow Volume (m3/h): 750
-
Refrigerant Type: R-32
-
Refrigerant Amount (G): 750
Indoor & Outdoor Parameters
-
Indoor Net Dimension (L*W*H) mm³: 910*215*320
-
Indoor Packing Net Dimension (L*W*H) mm³): 1032*318*418
-
Indoor Net Weight (kg): 11.5
-
Indoor Gross Weight (kg): 13.6
-
Outdoor Net Dimension (L*W*H) mm³: 700*245*535
-
Outdoor Packing Net Dimension (L*W*H) mm³: 845*320*593
-
Outdoor Net Weight (kg): 26
-
Outdoor Gross Weight (kg): 29
Features
-
Cooling: Yes
-
Heating: Yes
-
Dry: Yes
-
Vertical Flapper Auto Swing: Yes
-
Horizontal Louvers Auto Swing: Yes
-
Air-Purification With UV Technology: Yes
-
WiFi: Yes
-
Self-Clean: Yes
-
Anti-Corrosion: Yes
-
Turbo Function: Yes
-
UPS Enable: Yes
Accessories
-
Installation Kit (Liquid side) Material*Length*Dia*Thickness (mm): Copper * 2920*6*0.65 (6mm)
-
Installation Kit (Gas side) Material*Length*Dia*Thickness (mm): Copper * 2920*9*0.65 (9mm)
-
Power Cable (Core*mm²): 3*1.5
-
Communication Cable b/w Indoor & Outdoor (Core*mm²): 4*1.5
Warranty
-
Compressor: 10 Years
-
PCB Kit: 4 Years
-
Parts: 1 Yers
